- Up to 1920×1080@25fps
- Color: 0.001lux@ (F1.5, AGC ON), B/W: 0lux with IR
- S+265/H.265/H.264/M-JPEG
- Optical Zoom 23X
- IR Range Up to 150m
- Built-in Micro SD card slot, up to 512 GB
- Support Smart surveillance
- Support Human/Vehicle Classification
- Operating Conditions -30℃～65℃(IR OFF) -30℃～
- 40℃(IR ON), 0-95%
- DC12V±10%, POE IEEE802.3AT
- IP66
| Camera | |||||
| Image Sensor | 1/2.8″CMOS | ||||
| Min. Illumination | 0.001lux@ (F1.5, AGC ON), B/W: 0 lux with IR | ||||
| Shutter Time | 1s~1/100000s | ||||
| Day & Night | IR-cut filter with auto switch (ICR) | ||||
| WDR | 120dB | ||||
| Lens | |||||
| Focal Length | 5mm~115mm | ||||
| Optical Zoom | 23X | ||||
| Zoom Speed | <5s | ||||
| Aperture Range | F1.5~F3.0 | ||||
| Field of View | 55.8°~3.2°(H); 32.2°~1.8°(V); 61°~3.64°(D) | ||||
| Focus Control | Auto/Semi-auto/Manual | ||||
| Iris Control | Auto | ||||
| Close Focus Distance | 1000mm~1500mm | ||||
| DORI Distance | Detect:1351m Observe:536m Recognize:270m Identify:135m | ||||
| Pan & Tilt | |||||
| Pan Range | 360° | ||||
| Tilt Range | -16°～90° (Default -3°～90°) | ||||
| Tilt Speed | Manual Speed:0.1°～80°/s Preset: 80°/s |
||||
| 3D Position | Yes | ||||
| Preset | 500 | ||||
| Cruise | 16, up to 32 presets per cruise | ||||
| Scan | 8 | ||||
| Pattern | 8, each with 600s memory or 1000 orders | ||||
| Scheduled Task | Preset、Cruise、Scan、Pattern | ||||
| North Point | Yes(Manual setting) | ||||
| Power-off Memory | Yes | ||||
| Illuminator | |||||
| IR LEDs | 7 | ||||
| IR Distance | Up to 150m | ||||
| Wavelength | 850nm | ||||
| IR Irradiation Angle | Adjustable by Zoom | ||||
| Compression Standard | |||||
| Video Compression | S+265/H.265/H.264/M-JPEG | ||||
| Video Bit Rate | 32Kbps~16Mbps | ||||
| Audio Compression | G.711A/G.711U/ADPCM_D/AAC_LC | ||||
| Audio Sampling Rate | 8KHz/32KHz/48KHz | ||||
| Image | |||||
| Max. Resolution | 1920×1080@25fps | ||||
| Main Stream | PAL:25fps(1920×1080, 1280×720, 640×480, 704×576) NTSC:30fps(1920×1080, 1280×720, 640×480, 704×480) |
||||
| Sub Stream | PAL:25fps(704×576, 704×288, 352×288, 640×360) NTSC:30fps(704×480, 704×240, 352×240, 640×360) |
||||
| Third Stream | PAL:25fps(352×288) NTSC:30fps(352×240) |
||||
| BLC | Yes | ||||
| HLC | Yes | ||||
| AGC | Yes | ||||
| White Balance | Yes | ||||
| ROI | 7 Dynamic Areas for Both Main and Sub Stream | ||||
| OSD | 5 regions(Each region can have a maximum of 127 characters ,up to 1 line); 16*16/24*24/32*32/48*48/64*64/adaptable size; Vector/Lattice |
||||
| Defog | Yes | ||||
| Flip | Normal/Horizontal Mirror/Vertical Mirror/Inverted Flip | ||||
| Regional Exposure | Yes | ||||
| Regional Focus | Yes | ||||
| Demist | Yes | ||||
| Feature | |||||
| Alarm Trigger | Motion Detection; Mask Alarm; Voltage Alarm; Disk Full; Disk R/W Error; Recording Exception; IP Address Conflict; MAC Address Conflict; FTP Server Exception ; Event Input,Event Output; Network cable disconnected |
||||
| Linkage Method | send email; trigger sound; trigger recording; trigger capture; notify surveillance center | ||||
| Video Analytics | Human/Vehicle Classification; Tripwire; Double Tripwire; Perimeter; Object Abandon; Object Lost; Heatmap; Video Abnormal; Audio Abnormal | ||||
| Network | |||||
| ANR | Yes | ||||
| Protocols | HTTP; HTTPS; TCP/IP; UDP; UPnP; ICMP; IGMP; SNMP v1\v2\v3; DHCP; DNS; DDNS; Easy DDNS; NTP; SMTP; TLS; SSL; 802.1x; QoS; IPv4; IPv6; PPPOE; SSH; Unicast; Multicast; ARP; RTP; SRTP; RTSP; FTP; SFTP; PING |
||||
| System Compatibility | ONVIF Profile S/T/G/M; CGI; Milestone; RTMP | ||||
| Remote Connection | ≤2 | ||||
| Client | Easy7 VMS | ||||
| Mobile Client | EasyLive Plus | ||||
| User/Host | Up to 32 users. 4 user levels | ||||
| Interface | |||||
| Communication Interface | 1*RJ45 10M/ 100M self adaptive Ethernet port | ||||
| Audio I/O | 1*Input Impedance 1kΩ,2.0~2.4Vp-p; 1*Output Impedance 600Ω | ||||
| Alarm I/O | 1,Switching; 1,Switching,Voltage≤DC24V,Current≤1A | ||||
| Reset Button | Yes | ||||
| On-board storage | Built-in Micro SD card slot, up to 512GB | ||||
| General | |||||
| Web Client Language | 19 languages Simple Chinese/English/Traditional Chinese/Spanish/Italian/ Korean/Turkish/Russian/Thai/Polish/French/Dutch/ Hebraism/Vietnamese/Arabic/German/ Ukrainian /Portuguese/Albanian |
||||
| Operating Temperature | -30℃～65℃(IR OFF) -30℃～40℃(IR ON) |
||||
| Operating Humidity | 0-95% | ||||
| Storage Temperature | -30℃～65℃ | ||||
| Storage Humidity | 0%~95%RH(non-condensing) | ||||
| Power Supply | DC12V±10%; POE IEEE802.3AT | ||||
| Protection | Surge protection 4000V; Lightning proof 6000V; IP66 | ||||
| Material | Metal and Plastic | ||||
| Boundary Dimensions | 161mm(D)x276mm(H) | ||||
| Package Dimensions | 161mm(D)x276mm(H) | ||||
| Gross Weight | 3.8kg | ||||
| Net Weight | 2.1kg | ||||
- 2MP
- Optical Zoom: 23X
- Support smart surveillance
- Support human/vehicle classification
- IR range up to 150m
- Built in PoE
