- 16*10/100M POE ports + 2* 1000M Ethernet Uplink ports +1*1000M SFP Port;
- Comply with IEEE 802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z standards;
- Ethernet port 10/100M rate auto adaptive; n PoE port is in Extend mode, and ports 1-16 force 10M to automatically turn on AI mode;
- Supports POE priority, in order from 1 to 16 ports, enabled by default;
- Flow control method: IEEE 802.3x standard is used for full duplex, and Back pressure standard is used for half duplex;
- Zero configuration feature, automatically supplied to adaptive devices;
- Monitor the working status of the panel indicator light and assist in fault analysis;
- It is equipped with a three gear one key intelligent Dip switch, which supports VLAN, Default and Extend modes;
- Support port lightning surge: common mode 4KV, differential mode 2KV; Electrostatic ESD: air 8KV, contact 6KV. (level B)
- 16 x 10/100Mbps PoE Ports
- 2 x 10/100Mbps RJ45 Uplink Ports
- 1 x 1000M SFP Port
